Five Crucial Steps To Choose Vibrating Screen

Many mine owners are meeting many troubles like vibrating screen can’t reach the expected processing capacity or low screening efficiency in the process of production. As an important equipment, the screening efficiency of vibrating screen will directly affect the finished product quality and investment cost.

Generally, the screening efficiency of a vibrating screen is related to several factors such as material nature, equipment structure and various performance parameters. Apart from the basic requirements of choosing vibrating screen (material nature and equipment structure), today we mainly analyze 5 important performance parameters which relate to the efficiency of vibrating screen: There are amplitude, vibration frequency, vibration direction angle, screen surface inclination Angle and projectile Angle.

Amplitude Of Vibrating Screen

In general, the larger the size of the vibrating screen, the larger the amplitude selected. That’s because the larger amplitude means there will be less of screen hole plugging, this will be more conducive to ore screening stratification and realize a better screening capacity. But it should be noted that: if the amplitude of the vibrating screen is too large, strong vibration action may damage the equipment itself.

The vibration screen amplitude is usually determined by the particle and nature of ore. For example, when the ore particles are small and moist with a certain viscosity, we need to use vibrating screen with low frequency and large amplitude.

In addition, the corresponding amplitude and frequency should also be acted for different screening stages. For example, screening operation before selection generally use vibrating equipment with low frequency and large amplitude, and vibrating screen with high frequency and small amplitude are used in dewatering and desorption operations.

Vibration Frequency

The vibration frequency has a direct effect on the run-out state of ore particles on the screen. Vibration frequency that is too high or too low is not beneficial to the screening efficiency. Studies have shown that no matter what kind of screening is carried out on the vibrating screen, it is an ideal option for vibration frequency to maintain between 850 -1000 times a minute.

Under the same vibration intensity, if the frequency of vibrating screen is too low, the weight of the eccentric block of the vibrator will increase, which is not economical. On the contrary, higher frequency can greatly affect the speed of ore; this will decrease the processing power.

Therefore, vibration frequency can't be randomly adjusted. In order to make the vibrating screen play the ideal performance, user should adjust to the vibration frequency according to actual situation.

Screen Surface Inclination Angle

The screen surface inclination Angle refers to the angle between the screen surface and the horizontal plane, the magnitude of the Angle is related to the vibrating screen processing capacity and screening efficiency. When the screen surface inclination Angle increases, the movement speed of ore particles on the screen surface will be faster, and the processing capacity will be increased, but at the same time, the ore particles will stay on the screen surface for a correspondingly shorter time, thus affecting the screening efficiency, and vice versa.

Vibration Direction Angle

The vibration direction angle refers to the angle between the screen motion direction and the screen surface. When users decide to adjust the vibration direction angle, they should consider the nature of the ore being sifted firstly. For the ore with high density, small particle or easily crushed, it should be handled by vibrating screen with big vibration direction angle. For ore with high water content, strong viscosity or wear resistance, the vibration direction angle should be adjusted to small.

In actual production, most linear vibrating screens adopt vibration direction angles of 30°, 45° and 60°. That‘s because this kind of angle can not only adapt to various screening performance, but also obtain the best moving speed and screening efficiency.

Projectile Angle Of Vibrating Screen

According to the screening theory and practice, the magnitude and strength of the projectile Angle of the vibrating screen have a direct influence on the screening ore. When the ore projectile intensity increases, the inertia force is also increased; thus the ore can be thrown higher, which is more conducive to the ore handling. However, too much projectile intensity will inevitably affect the screen box, making it premature damage. Therefore, user should consider the strength of vibration screen box structure to determine the projectile Angle.
